Digital Point Load Test Apparatus with Manuel Hydraulic, Pomp and Hydraulic Cylinder 70 kN

Standards

ASTM D5731, ISRM

The UTR-0540 Digital Point Load Test Apparatus is used for determining the strength values of a rock specimen, both in the field and in the laboratory.

Consists of a 70 kN capacity load frame with an upper and lower conical platens, a digital pressure/force manometer and a hydraulic loading cylinder.

A ruler assembled on the frame allows the direct measurement of the distance between the conical platens before and after the test.

The compression load is measured by a pressure transducer connected to an advanced digital easily transportable wooden case.

UTR-0544 Loading platens for compression and indirect/splitting tensile tests on rock specimens should be ordered seperately.

Supplied complete with face protective goggles and carriage box. Loading platens set for compression and indirect/splitting tensile strength test should be ordered separately.

SPECIFICATION

• Load Capacity : 70 kN
• Resolution : 32.000 div.
• Piston stroke : 115 mm
• Distance between conical platens: 114 mm
• Distance between columns: 110 mm
• Distance between compression platens: 126  mm
